Linear Actuator
Products Description:
GDLA201 is linear Actuator, is widely used in various industry equipment, boat, vehicles and high load output extremely harsh conditions.
| Model NO. | GDLA201 |
| Voltage | DC12V/24V/48V |
| Stroke | 50-2800mm do the length as per clients' request |
| Max. Load | 500N |
| Speed | 6.5-60mm/s |
| IP Grade | IP54 |
| Operation Temperature | -40-65 Centigrade Temperature |
| Certificate | CE |
Delivery time: 10 days for stock ones, for OEM custom-made ones delivery time is 20 days.
The package is: standard export carton box and pallets.
GDLA201 Linear actuator All aluminum alloy material package, material structure design is tight, using dc reducer Wheel deceleration, built-in micro switch, can achieve automatic stop after travel, travel can be set Easy to install and easy to operate; Widely used in agriculture, construction, mining, Forestry, road operation, railway equipment and other complex working environment, can effectively replace hydraulic pressure Pneumatic equipment. • operating temperature -40°C~+65°C • aluminum alloy tube and stainless steel shaft • protection level IP66 •12, 24, 36, 48VDC • built-in micro switch • maximum thrust 500N
